THE LATEST INNOVATION IN CAMERA DOLLIES

The Kessler Shuttle Dolly is the latest innovation in camera dollies and finally provides filmmakers with the performance and versatility dollies in its class have always lacked. The Shuttle Dolly utilizes standard speed rail and can be operated manually or in conjunction with Kessler's motion control solutions - CineDrive, Second Shooter and Second Shooter Plus.






The Kessler Kwik Rail is custom machined threaded speed rail that can be configured into variable lengths for use with Shuttle Dolly and other speed rail compatible dollies on the market today. What makes Kwik Rail unique is that by eliminating the need for connectors or coupling devices to attach two pieces of rail together we’ve eliminated those unnecessary parts that can get lost and introduce more seams to the dolly rail and instead designed Kwik Rail to have the rails themselves threaded. The integrated Kwik Thread™ design makes the connection between rail sections very secure and  incredibly fast, up to four times faster than traditional speed rail - saving time, money and frustration on set.

The Kwik Rail comes in two sizes, 4’ (42.375”) and 2’ (23.875”) and includes aluminum thread protectors that will ensure your threads are not damaged during travel or in-use. The anodized 6061 T6 aluminum schedule 80 pipe used for the Kwik Rail has thicker walls than many other speed rails available, increasing durability and ensuring maximum weight bearing, yet is drastically lighter than traditional steel speed rail. The precision grind on the Kwik Rail is second to none and provides a seamless transition from section to section.

There’s zero question, when you purchase the Kessler Kwik Rail you are getting the absolute highest quality variable length screw together rail available.







KWIK RAIL 24" (SET OF 2)

MSRP $215.00

The Kwik Rail 24" set provides users with 2 pieces of 24" custom machined threaded speed rail and 2 custom machined protective end caps.


KWIK RAIL 42" (SET OF 2)

MSRP $250.00

The Kwik Rail 42" set provides users with 2 pieces of 42" custom machined threaded speed rail and 2 custom machined protective end caps.


KWIK RAIL LEG SYSTEM

MSRP $999.90

The complete Kwik Rail Leg System provides users with everything they need to use Kwik Rail as the supports for the Shuttle Dolly, including four 42’ Kwik Rail segments used as the legs, four Kwik Rail Clamps that feature a safety-lock mechanism for attaching the legs to the dolly track rail and four rubber Kwik Rail Foot Adapters.



ACCESSORIES



HARD CASE

MSRP $199.95

With the optional Kwik Rail case users will find that mobility and organization were key to the Kwik Rail’s development and will have an ideal case to both protect and deliver their rail to each location.

Kwik Rail Leg Clamps

MSRP $399.95 (Set of 4)

Kwik Rail Leg Clamps allow you to use Kwik Rail or standard speed rail as adjustable legs for the shuttle dolly.


Shuttle Dolly Motor Mount

MSRP $199.95

The Shuttle Dolly Motor Mount allows you to mount one of our motion control slider motors to the Shuttle Dolly


Shuttle Dolly Keeper/Grabber Wheels w/ Brake

MSRP $299.95

Keeper/Grabber Wheels ensure that the Shuttle Dolly Platform will not be able to fall off of the speed rail you are using.  Keeper/Grabber Wheels are compatible with Speed rail ranging from 1.25" - 2" in diameter.  The brake is compatible with speed rail ranging from 1.25" - 1.5" in diameter.



Stand Adapter

MSRP $24.95

The 3/8”-16 to Female Baby / Male Junior Pin Adapter is used mount your slider, Shuttle Dolly Clamps/Supports or other accessories to stands with a standard Male Baby Pin (5/8”) or a Female Junior Pin Receiver (1-1/8”).


Mitchel Adapter Plate Insert

MSRP 129.95

A Mitchell Camera Plate insert can be connected for large format film tripod heads and accessories.


Kwik Rail Foot Adapters

MSRP $99.95

Available with adjustable rubber or spike feet this is must have when using the Kwik Rail as legs for your Shuttle Dolly system.


Basic Center Rail Support

MSRP $39.99

Tthe Basic Center Rail Support provide a platform for the speedrail to be placed on.




Deluxe CENTER RAIL SUPPORT

MSRP $79.99

Gives you the same amazing support as the Basic but thanks to the adjustable feet the Deluxe allows your to level the speedrail


Center Rail Ground Support

MSRP $99.99

Use the Shuttle Dolly Center Rail Ground Support to support Speed Rail every 5 feet when doing a set up on the ground. Use the optional 3/8"-16 to Female Baby / Male Junior Pin Adapter to mount on your stands with a standard Male Baby Pin (5/8”) or a Female Junior Pin Receiver (1-1/8”).




The Shuttle Dolly improves upon standard market offerings by integrating an optional keeper system and brake for angled incline/decline shooting, optional drag control, an integrated and extendable foot system as well as various mounting solutions including mitchell mount, 100mm bowl mount and cheese plate. The Shuttle Dolly can also be supported via tripods and c-stands when not using Kessler’s proprietary integrated foot system.



BUILD QUALITY

Solid billet aluminum construction, custom casted and machined urethane dolly wheels, precision stainless steel bearings and a flat black anodized finish give the Shuttle Dolly the appearance and quality Kessler customers have come to expect out of every product we manufacture. Zero shortcuts in production and no off-the-shelf components mean this tool will work as hard as you do and last even longer.

EASY AND CONFIGURABLE SET-UP

Speed rail and end clamps mount to tripods and light stands (baby or junior stands) in seconds allowing users to start filming in no time. Utilizing Shuttle Dolly's integrated adjustable feet or optional adjustable speed rail legs (coming soon) provide mounting solutions for any filming environment.

CAPACITY AND SECURITY

The Shuttle Dolly can handle up to 125 lbs and can be used in various inclined and declined shooting situations by utilizing its optional keeper/grabber system. For added safety the Shuttle Dolly also includes an optional brake to ensure your rig is secure (compatible with speed rail from 1 1/4" - 1 1/2").



BUILT ON THE STANDARDS - AND THEM SOME

Users can utilize various sizes speed rail depending on availability and need. The Shuttle Dolly can be used on speed rail of any diameter between 1 1/4" to 2”  The keeper/grabber system will also work within that entire range.

MANUAL OPERATION AND MOTION CONTROLLED

Unlike it's competitors and predecessors the Shuttle Dolly can be operated manually, with or without an optional drag control module AND can be motorized with Kessler’s motion control solutions - CineDrive and Second Shooter. Combined with the world's most powerful motion control software in its class, kOS, the Shuttle Dolly is in a league of its own.

MOUNTING OPTIONS

A variety of camera and rig mounting options include Mitchell mount, 100mm bowl mount and cheese plate.
